Pot d’étalonnage standard et exécution spéciale
Pot d’étalonnage en Pyrex ou tout
en acier inoxydable AISI 316L
Pot d’étalonnage ou tout en acier inoxydable AISI 316L Temp. nominale 220 °C
Pot d’étalonnage ou pyrex « classique » et Brides AISI 316L
- All
- 100 ml
- 10000
- 25000
SCALE (Lt): 10
HEIGHT (mm): 656
FLANGE DIAM. (mm): 195
IN/OUT CONNECTIONS: 1″ NPT
SCALE (Lt): 10
HEIGHT (mm): 693.2
FLANGE DIAM. (mm): 209
IN/OUT CONNECTIONS: 3/4″ RF
SCALE (Lt): 10
HEIGHT (mm): 669.2
FLANGE DIAM. (mm): 199
IN/OUT CONNECTIONS: 1″ 150RF
SCALE (Lt): 10
HEIGHT (mm): 662
FLANGE DIAM. (mm): 199
IN/OUT CONNECTIONS: 1″ 600RF
SCALE (Lt): 15
HEIGHT (mm): 628
FLANGE DIAM. (mm): 219.1
IN/OUT CONNECTIONS: 1″ NPT
SCALE (Lt): 15
HEIGHT (mm): 628
FLANGE DIAM. (mm): 219.1
IN/OUT CONNECTIONS: 1 1/2″ NPT
SCALE (Lt): 15
HEIGHT (mm): 628
FLANGE DIAM. (mm): 219.1
IN/OUT CONNECTIONS: 1 1/2″ RF
SCALE (Lt): 20
HEIGHT (mm): 858
FLANGE DIAM. (mm): 219.1
IN/OUT CONNECTIONS: 1″ NPT
SCALE (Lt): 20
HEIGHT (mm): 858
FLANGE DIAM. (mm): 219.1
IN/OUT CONNECTIONS: 1 1/2″ NPT
SCALE (Lt): 20
HEIGHT (mm): 858
FLANGE DIAM. (mm): 219.1
IN/OUT CONNECTIONS: 1″ RF
SCALE (Lt): 20
HEIGHT (mm): 858
FLANGE DIAM. (mm): 219.1
IN/OUT CONNECTIONS: 1 1/2″ 150RF
SCALE (Lt): 25
HEIGHT (mm): 860
FLANGE DIAM. (mm): 269
IN/OUT CONNECTIONS: 1″ RF
SCALE (Lt): 25
HEIGHT (mm): 860
FLANGE DIAM. (mm): 269
IN/OUT CONNECTIONS: 1 1/2″ 150RF
SCALE (Lt): 2
HEIGHT (mm): 448
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 1″ NPT
SCALE (Lt): 2
HEIGHT (mm): 542
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 1/2″ 150RF
SCALE (Lt): 2
HEIGHT (mm): 521
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 3/4″ 300RF
SCALE (Lt): 2
HEIGHT (mm): 525
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 1″ 150RF
SCALE (Lt): 3
HEIGHT (mm): 563
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 3
HEIGHT (mm): 563
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 3
HEIGHT (mm): 563
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 1″ NPT
SCALE (Lt): 3
HEIGHT (mm): 644
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 1/2″ 150RF
SCALE (Lt): 4
HEIGHT (mm): 437
FLANGE DIAM. (mm): 165
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 4
HEIGHT (mm): 467
FLANGE DIAM. (mm): 165
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 4
HEIGHT (mm): 547.6
FLANGE DIAM. (mm): 169
IN/OUT CONNECTIONS: 1″ 150RF
SCALE (Lt): 5
HEIGHT (mm): 532
FLANGE DIAM. (mm): 165
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 5
HEIGHT (mm): 536
FLANGE DIAM. (mm): 165
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 5
HEIGHT (mm): 538
FLANGE DIAM. (mm): 165
IN/OUT CONNECTIONS: 1/2″ 150RF
SCALE (Lt): 5
HEIGHT (mm): 538
FLANGE DIAM. (mm): 165
IN/OUT CONNECTIONS: 1″ 150RF
SCALE (Lt): 7.5
HEIGHT (mm): 529
FLANGE DIAM. (mm): 195
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 7.5
HEIGHT (mm): 521
FLANGE DIAM. (mm): 195
IN/OUT CONNECTIONS: 1″ NPT
SCALE (Lt): 7.5
HEIGHT (mm): 532.6
FLANGE DIAM. (mm): 199
IN/OUT CONNECTIONS: 1/2″ 600RF
SCALE (Lt): 7.5
HEIGHT (mm): 527
FLANGE DIAM. (mm): 199
IN/OUT CONNECTIONS: 1″ 600RF
SCALE (Lt): 10
HEIGHT (mm): 664
FLANGE DIAM. (mm): 195
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 0.1
HEIGHT (mm): 302
FLANGE DIAM. (mm): 65
IN/OUT CONNECTIONS: 3/8″ NPT
SCALE (Lt): 0.1
HEIGHT (mm): 302
FLANGE DIAM. (mm): 65
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 0.1
HEIGHT (mm): 397
FLANGE DIAM. (mm): 98.4
IN/OUT CONNECTIONS: 1/2″ 150RF
SCALE (Lt): 0.25
HEIGHT (mm): 288.4
FLANGE DIAM. (mm): 80
IN/OUT CONNECTIONS: 3/8″ NPT
SCALE (Lt): 0.25
HEIGHT (mm): 296
FLANGE DIAM. (mm): 80
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 0.25
HEIGHT (mm): 296
FLANGE DIAM. (mm): 80
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 0.25
HEIGHT (mm): 376
FLANGE DIAM. (mm): 90
IN/OUT CONNECTIONS: 1/2″ 150RF
SCALE (Lt): 0.5
HEIGHT (mm): 494
FLANGE DIAM. (mm): 80
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 0.5
HEIGHT (mm): 494
FLANGE DIAM. (mm): 80
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 0.5
HEIGHT (mm): 572
FLANGE DIAM. (mm): 90
IN/OUT CONNECTIONS: 1/2″ 150RF
SCALE (Lt): 1
HEIGHT (mm): 479
FLANGE DIAM. (mm): 105
IN/OUT CONNECTIONS: 1/4″ NPT
SCALE (Lt): 1
HEIGHT (mm): 479
FLANGE DIAM. (mm): 105
IN/OUT CONNECTIONS: 3/8″ NPT
SCALE (Lt): 1
HEIGHT (mm): 479
FLANGE DIAM. (mm): 105
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 1
HEIGHT (mm): 479
FLANGE DIAM. (mm): 105
IN/OUT CONNECTIONS: 3/4″ NPT
SCALE (Lt): 1
HEIGHT (mm): 479
FLANGE DIAM. (mm): 105
IN/OUT CONNECTIONS: 1″ NPT
SCALE (Lt): 1
HEIGHT (mm): 575.8
FLANGE DIAM. (mm): 105
IN/OUT CONNECTIONS: 1/2″ 150RF
SCALE (Lt): 1
HEIGHT (mm): 575.8
FLANGE DIAM. (mm): 105
IN/OUT CONNECTIONS: 3/4″ 150RF
SCALE (Lt): 1
HEIGHT (mm): 552.4
FLANGE DIAM. (mm): 108
IN/OUT CONNECTIONS: 1″ 150RF
SCALE (Lt): 2
HEIGHT (mm): 448
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 1/2″ NPT
SCALE (Lt): 2
HEIGHT (mm): 448
FLANGE DIAM. (mm): 125
IN/OUT CONNECTIONS: 3/4″ NPT
|
some examples : |
|||
|
Scale – Lt |
Height Altezza h (mm) |
Flange diam.(F) mm |
In/out Connections |
|
0,25 |
292 |
75 |
1/2″ NPT |
|
0,5 |
495 |
75 |
1/2″ NPT |
|
1 |
480 |
100 |
1/2″ NPT |
|
2 |
450 |
130 |
1/2″ NPT |
|
3 |
640 |
130 |
1/2″ NPT |
|
10 |
500 |
240 |
1″ NPT |
Matériaux : Pyrex, polycarbonate
Bride : AISI 316, AISI 304, PVC
Toutes les dimensions
Tous les matériaux de votre choix
